Stepper Motor Data
Small
Square
Round
Ben Wirz archive
Casa archive
| Stepper Description | ||
|---|---|---|
| Model | MSCS048A96 (PQJQ10011ZB-S) | |
| Manufacturer | Sankyo | |
| Drive method | - | |
| Number of phases | 4 | |
| Winding colours | red (common), brown, orange, yellow, black | |
| Step angle | °/step | - |
| Voltage | V | - |
| Current | A/phase | - |
| Winding resistance | ohm/phase | 96 |
| Inductance | mH/phase | - |
| Holding torque | mN*m | - |
| Detent torque | mN*m | - |
| Rotor inertia | g*cm*cm | - |
| Weight | g | - |
| Insulation Class | - | |
| Insulation resistance | - | |
| Dielectric strength | - | |
| Operating temperature range | °C | - |
| Allowable temperature rise | ° | - |
Examples
Recovered from Panasonic KX-F2750NZ fax :
